The GT Force-32 CNC Lathe is a compact gang tool machine engineered for precision and efficiency, making it ideal for small to medium-sized part production. With spindle speeds up to 6,000 RPM and a 32mm bar capacity, the GT Force-32 handles a range of turning and milling operations with speed and accuracy. Its compact design allows for efficient use of floor space, while the gang tool configuration minimizes tool change times, enhancing productivity. The Meehanite cast base ensures rigidity and vibration dampening, providing excellent precision for high-demand machining tasks.
- Spindle speeds up to 6,000 RPM
- 32mm bar capacity for diverse part sizes
- Compact design for space efficiency
Lathe
GT Force-32 CNC Lathe Technical Specifications
The GT Force-32 Compact Gang Tool Lathe is designed to deliver high-performance machining in a space-efficient footprint. It features spindle speeds of up to 6,000 RPM and accommodates a 32mm bar capacity, making it ideal for a range of precision turning and milling operations. The gang tool setup allows for rapid tool changes, significantly reducing cycle times and boosting productivity. The machine is built on a Meehanite cast base, providing excellent rigidity and vibration dampening, ensuring precision even during high-speed machining.Additionally, the automatic lubrication system helps maintain accuracy and extend machine life. The FANUC control system provides reliable and user-friendly operation, while the compact design optimizes floor space utilization. Below, all standard specifications are covered. Contact us today for a custom quote tailored to your specific machining needs.Machining Capacity
- 5C Collet: Ø 1-1/16 in. / Ø 27 mm
- Dead-Length Collet Chuck: Ø 1-3/16 in. / Ø 30 mm
- High Precision Air Chuck: Ø 3-5/32 in. / Ø 80 mm
- 5″ Hydraulic 3-Jaw Chuck: Ø 3-5/32 in. / Ø 80 mm
- Diaphragm Chuck: Ø 3-5/32 in. / Ø 80 mm
- Max Turning Length: 2.36 in. / 60 mm
Spindle
- Through Hole: Ø 1.77 in. / Ø 45 mm
- Draw Tube: Ø 1.38 in. / Ø 35 mm
- Motor Drive: FANUC 7.5 HP / 3.7 / 5.5 kW
- Max Speed: 6000 rpm
Axis
- Type: Linear ways
- X-Axis Stroke: 8.27 in. / 210 mm
- Z-Axis Stroke: 7.87 in. / 200 mm
- X-Axis Servo Motor: 1 HP / 0.75 kW
- Z-Axis Servo Motor: 1 HP / 0.75 kW
- X/Z-Axis Rapid Speed: 787.40 in./min / 20 m/min
Tools
- Number of Tools: 6 (2 OD and 4 ID)
- Turning Tool: 0.63 in. (opt. .47″, .79″) / 16 mm
- Drill Shank: Ø 3/4 in. / Ø 20 mm
General
- Hydraulic Unit: 0.56 HP / 0.4 kW
- Coolant Tank Capacity: 29 gallons / 110 L
- Coolant Pump: 0.75 HP / 0.56 kW
- Floor Space: L31.5 x W66 x H70.87 in. / L800 x W1680 x H1800 mm
- Weight: 3792 lbs. / 1720 kg
- Power Supply: AC / 3PH / 220V
- CNC Controller: FANUC Series Oi – TF
Multiple Loading Options:
The GT Force-32 offers various automated loading solutions, including options such as Epson Flexion N2 Compact 6-Axis Robots, 12 Station Rotary Stacker, 10 Tray Palletizer, and conveyor systems. These ensure streamlined and efficient part handling for high-volume production.Different Chucking Options Available:
The machine supports multiple chucking configurations, including 5C Collet, Dead-Length Collet, High Precision Air Chuck, 5″ Hydraulic 3-Jaw Chuck, Diaphragm Chuck, and Hainbuch ID Mandrel, providing flexibility for different workholding needs.C-axis standard with 0.08º accuracy:
The GT Force-32 comes with a standard C-axis that delivers precise rotational control with 0.08º accuracy, making it ideal for angular cutting and complex machining operations.FANUC Series Oi – TF Control:
Equipped with the reliable FANUC Series Oi – TF Control, this system ensures fast, user-friendly CNC operations with high precision and consistent performance.6 Tools (2 OD and 4 ID):
The machine accommodates up to 6 tools, featuring 2 OD tools and 4 ID tools, offering versatility in tool configurations for different machining operations, allowing for more efficient processing.Tooling System:
The Tooling System is designed to maximize performance and accuracy. It supports a wide range of tools, with quick-change capabilities that enhance productivity by reducing setup times and ensuring precise cutting.
GANG
Discover the power of the GT Force-32 Compact GANG TOOL WITH C-AXIS by Cubic Machinery! If you have questions or need more info, just submit your request, and our team will help you. Elevate your production with the GT Force-32 Compact GANG TOOL !
How Can the GT Force-32 Compact GANG TOOL Improve Your Manufacturing Process?
Process
The GT Force-32 Compact GANG TOOL Lathe can significantly enhance your manufacturing process by improving efficiency, precision, and flexibility. Designed for high-speed machining, this machine minimizes non-cutting time with rapid traverse rates of up to 787.40 in./min (20 m/min), reducing overall cycle times and increasing throughput. With its compact design, the GT Force-32 saves valuable floor space while still providing powerful machining capabilities, making it ideal for production environments where space is limited.
Equipped with a FANUC Series Oi-TF control system, the machine ensures precise, reliable operations and easy-to-use programming, allowing for smooth integration into your existing workflow. The versatile workholding options, such as 5C collet, dead-length collet, and high-precision air chucks, cater to various part geometries, improving part gripping and stability during operations. The C-axis control with 0.08º accuracy allows for complex angular cuts and milling operations, ensuring precise results for intricate parts.
By using a 6-tool gang tool configuration (2 OD and 4 ID tools), the machine achieves faster tool changes and greater rigidity compared to turret-based lathes, further improving cycle times and maintaining consistent accuracy. With automated loading options, such as 6-axis robots and rotary stackers, the GT Force-32 reduces manual intervention, enabling a more streamlined, automated production process that maximizes output and minimizes labor costs.
Why Choose Cubic Machinery CNC Lathe?
Frequently Asked Questions about the GT Force-32 Compact Gang Tool Lathe
FAQ
The GT Force-32 Compact Gang Tool Lathe is a versatile and efficient machining solution designed for high-precision production of small to medium-sized parts. This FAQ section addresses common questions about the GT Force-32’s features, capabilities, and applications. We cover topics such as the machine’s compact design, gang tooling configuration, automatic loading system, and FANUC 0i-TF control with integrated gantry robot programming. Whether you’re considering the GT Force-32 for your manufacturing needs or looking to optimize its use, this FAQ aims to provide valuable insights into its performance, flexibility, and cost-saving benefits. If you don’t find the answer to your specific question here, please don’t hesitate to contact us for more detailed information.
What industries benefit most from using the GT Force-32 Compact Gang Tool Lathes?
The GT Force-32 Compact Gang Tool Lathe is well-suited for several industries that require precision machining of small to medium-sized parts. Some of the industries that would benefit most from using this machine include:
- Aerospace: Aerospace manufacturers can utilize the GT Force-32 for producing small, high-precision components like fasteners, fittings, and hydraulic parts. The machine’s high accuracy and ability to handle complex geometries make it ideal for aerospace applications.
- Medical Device Manufacturing: The medical device industry requires tight tolerances and excellent surface finishes for components like implants, surgical instruments, and diagnostic equipment. The GT Force-32’s precision and flexibility are well-suited for these demanding applications.
- Electronics: Electronics manufacturers can benefit from the compact design and fast tool changes of the GT Force-32 when producing small connectors, heat sinks, and other precision electronic components.
- Automotive: The automotive industry can use this machine for producing various small engine components, fuel system parts, and other precision automotive components that require tight tolerances.
- Job Shops: Small to medium-sized job shops can greatly benefit from the GT Force-32’s versatility and compact footprint. It allows them to take on a variety of turning jobs for different industries without requiring extensive floor space.
- Firearms Manufacturing: The firearms industry often requires precise, small parts production. The GT Force-32’s capabilities make it suitable for manufacturing firing pins, trigger components, and other small firearm parts.
The GT Force-32’s compact design, gang tooling configuration, and automation options make it particularly valuable for industries that need to increase productivity in secondary lathe operations while minimizing labor costs and floor space requirements.
What are the cost benefits of using the GT Force-32 in manufacturing?
The GT Force-32 Compact Gang Tool Lathe offers significant cost benefits in manufacturing through its combination of increased productivity, reduced labor costs, and space efficiency. Its gang tooling configuration enables rapid tool changes, boosting output and lowering cost per part. The automatic loading system and potential for unattended operation drastically cut labor expenses, while the compact design maximizes production capacity in limited floor space. The machine’s versatility reduces the need for multiple specialized tools, lowering overall equipment costs.
Improved accuracy leads to less waste and fewer rejected parts, further contributing to cost savings. Additionally, the potential for energy efficiency can result in lower operating costs. Together, these factors allow manufacturers to streamline their operations, reduce overhead, and ultimately improve their bottom line, making the GT Force-32 a cost-effective solution for various industries requiring precision machining of small to medium-sized parts.
What are the key features of the GT Force-32?
The GT Force-32 Compact Gang Tool Lathe offers several key features that enhance its performance, precision, and versatility:
Multiple Loading Options: The machine supports a variety of loading options, such as the Epson Flexion N2 Compact 6-Axis Robot, In and Out Conveyor Loading System, Track Loader with Vibratory Bowl, 12 Station Rotary Stacker, and 10 Tray Palletizer. These options improve automation and overall productivity.
Different Chucking Options: It accommodates several chucking systems, including 5C Collet, Dead-Length Collet, High Precision Air Chuck, 5” Hydraulic 3-Jaw Chuck, and Diaphragm Chuck. These options allow for versatility in holding different workpieces securely.
C-Axis with 0.08º Accuracy: The machine’s C-axis comes standard with 0.08º accuracy, enabling precise rotary operations, which are essential for complex part machining.
FANUC Series Oi-TF Control: The FANUC Series Oi-TF CNC Control ensures reliable and user-friendly machine operations with high programming capabilities and integrated automation options.
6 Tools Configuration: The GT Force-32 supports up to 6 tools (2 OD and 4 ID), allowing for multi-operation setups, reducing tool change time, and increasing efficiency.
Advanced Tooling System: The machine’s versatile tooling system provides flexibility for various cutting and drilling operations, making it a highly customizable solution for different production needs.
These features make the GT Force-32 ideal for manufacturers looking for precision, speed, and versatility in compact machining environments.
What are the benefits of using a FANUC 0i-TF control in the GT Force-32?
The FANUC 0i-TF control in the GT Force-32 offers significant benefits that enhance the machine’s overall performance and versatility. Its dual-channel capability, with one channel dedicated to the integrated gantry robot, allows for seamless synchronization of machine and robot operations, simplifying programming and improving efficiency.
The control supports C-axis functionality, enabling milling and off-center drilling operations, while its high-speed processing with 400 look-ahead blocks ensures smooth machining of complex contours. The system’s customization options, conversational programming through MANUAL GUIDE i, and integrated safety features make it user-friendly and adaptable to specific applications. Additionally, the high-speed PMC and renowned FANUC reliability contribute to minimizing downtime and maximizing productivity. These features collectively make the GT Force-32 a powerful and flexible solution for precision machining across various industries.
